5 Creating Measurement Scenes
5 - 46
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
5 Click on [OK].
The variable set is added to the end of the variable list with the following definition.
Integer type: Initial value = 0, value = 0, Comment: <empty string>
Floating point type: initial value = 0, value = 0.000000, Comment: <empty string>
Character string type: initial value = <empty string>, value = <empty string>, comment: <empty string>
Additional Information
The variable name displayed in the variable list is displayed as (**. Variable name ***) with the
type of variable and type identifier appended.
For Variable type, there are two types defined, SC (Scene variable) and SY (System variable).
The following is an example for the variable name "abc".
• Scene variable with "Integer": SC.abc&
• Scene variable with "Integer (Save)": SC.abc&&
• System variable with "Real number": SY.abc#
• System variable with "String array": SY.abc()
