5 - 49
5 Creating Measurement Scenes
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-4 Using Variables
 Non-array Type Variables:
1 On the Edit item tab area in the Edit flow tab screen, click [Scene variable] tab or [System vari-
able] tab.
The Scene variable tab screen or the System variable tab screen is displayed.
2 On the Variable list area, select a variable name to edit.
3 Click [...] at the right of the “Initial” column for the selected variable.
The “Initial value set form” dialog box is displayed.
4 Directly enter a value into the input text box or click [...] for it.
5 Click [OK] to end the input.
Editing the Initial Value of a Variable.
