Omron fh-1 series User Manual

8 - 71
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-4 Creating a Custom Dialog Box [Custom Dialog Functions]
8
8-4-2 Custom Dialog Tool
 Common Settings Area
Important
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
Settings in the Dialog Box Properties Display Area
Setting item
Setting value
[Factory default]
Description
Dialog ID The dialog box ID is set to
a character string that is
not assigned to any other
dialog box.
The ID for the dialog box.
To change the ID, click the [...] button and enter the desired
characters.
Dialog title A title that is based on the
dialog box type is
assigned.
The title for the dialog box. This appears in the title bar
when the custom dialog box is displayed.
To change the title, click the [...] button and enter the
desired characters.
Multilingual is also supported. For details, refer to 3-2-2
Inputting Text on page 3-7.
Dialog kind --- The dialog box type is displayed.
Display target scene
No.
Scene 0 to scene 127
*1
[Scene0]
*1. The setting for scene 0 to 1023 is available when the number of maximum scenes has been changed.
This specifies the number of the scene for which to display
the dialog box.
Display target unit No. This is set to the unit that
can be selected from the
display target scene.
This specifies the number of the unit for which the dialog
box is to be displayed instead of the default settings dialog
box.
The unit that can be specified depends on the type of the
dialog box.
Immediately after the dialog box is added, the unit with the
lowest unit number out of the display target units in the dis-
play target scene is selected.
If there is no display target unit, unit 0 is selected.
Unit label This specifies the unit label for which the dialog box is to be
displayed instead of the default setting dialog box. The unit
that can be specified depends on the type of the dialog box.
Beginning with searching the display target unit label and
then the display target unit number will be searched if no
corresponding unit label is found. If no display target unit is
found, unit 0 is selected.
Dialog X
Dialog Y
0 to 9999999 [0] Sets the dialog display position with the coordinate system
that the upper left position of the screen is (0,0).
If the set coordinates are out of the screen, the dialog box is
displayed at (0,0).
[Setting] Button Displays the set contents as the custom dialog box. Adjust
the dialog box position. After adjusting, the adjusted con-
tents will be reflected to the dialog box position X, dialog
position Y, dialog width, and dialog height by clicking the
[Close] on the right end of the dialog title bar.
