10 Advanced Usage
10 - 56
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
 Vision Master Calibration (Homing operation selection is Disabled.)
External device PLC
FH/FZ5
Outputs data
1: Moves to the axis
position when
Calibration is started.
Response that
movement is completed.
Repeats processing within
this frame until calibration
complete flag is ON (1).
2: Clear the measurement
results.
Response that clear
processing is completed.
3: Measurement Command
3.1: Measurement
Moves only each axis of next axis
movement amount when calibration
complete flag is OFF (0).
4: Moves only each axis of
next axis movement
amount
Response that
movement is completed.
• Next axis movement amount
(by each axis of external device)
• Calibration complete flag
