11 What to Do!
11 - 6
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Failed to paste.
Please check the save source or the save
destination.
• No more Scene can be added due to lack of memory.
*1
Review the inspection flow and reduce the memory consump-
tion or switch to another scene group.
*1. The display varies depending on the controller.
The remaining capacity of the application is not sufficient for
the FH series/FZ5-800/1100/1200 series.
The remaining data memory capacity is not sufficient for the
FZ5-L series/FZ5-600 series.
• The amount of memory used and free data memory can be
checked from the menu of Memory Consumption Monitor on the
Measurement Management Bar or the system menu.
Refer to 3-4 Checking the Memory Consumption and Percent-
age of Memory Used on page 3-31 and 3-3 Checking System
Information on page 3-27.
A camera outside the guarantee is con-
nected.
A camera outside the guarantee is connected to the controller cur-
rently being used.
Destination folder is not found. Please
check.
Check the following points.
• Have you deleted the destination folder?
• For cases where he save destination is the folder in the USB-
Disk, is the USBDisk connected to the controller?
Or, has the USBDisk been detected?
Failed to save the scene group data.
The current Scene group data in the flash
memory is discarded after restarting.
Recover or avoid by the following ways.
• After increasing free memory in flash by such actions as delet-
ing other Scene data, deleting processing units, or making mea-
surement regions or model sizes as small as possible, re-click
"Data Save."
• Change the save destination for the Scene group data to the
external storage device when the current save destination is set
to Sensor Controller.
Refer to 7-5 Saving Scene Groups in External Storage [Scene
Group Saving Destination Settings] on page 7-10.
• If the current Scene group is not saved, saves the current scene
group to an external storage device.
Refer to 9-3 Saving Setting Data to the Controller RAMDisk or
an External Storage Device on page 9-8.
• The amount of memory used and free data memory can be
checked from the menu of Memory Consumption Monitor on the
Measurement Management Bar or the system menu.
Refer to 3-4 Checking the Memory Consumption and Percent-
age of Memory Used on page 3-31 and 3-3 Checking System
Information on page 3-27.
PLC link error PLC link cannot be established. Check the following points.
• Are the FZ communication settings correct?
Refer to Communicating with PLC Link - Communications
Specifications Settings in Vision System FH/FHV/FZ5 Series
User’s Manual for Communications Settings (Cat. No. Z342).
• Are the PLC communication settings correct?
• Is cable connected correctly?
Refer to I/O Interface in Vision System FH/FZ5 series Hardware
Setup Manual (Cat. No. Z366).
Failed to register model For Search, Classification, Flexible search, Shape search II
Please register higher-contrast images as models. If the model is
registered at full screen size, re-register at a smaller size.
For Fine matching
The two pixels at the edge of the image cannot be registered as
the model.
Error message Troubleshooting
To Next Page
