5-1
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
5
In the Run view, you can observe the progress of the setup as it follows the parameters
you have defined. The right panel of the WebLink UI shows Counts for Cycles,
Reads, No Reads, and Mismatches, as well as Rate information for Capture,
Decode, Overhead, Total Read, and Trigger Rate, as well as Output Data. A
"filmstrip" below the Image Area shows each image capture with a green check
mark for a good read and a red x for a No Read.
5-1 Counts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5-2 Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5-3 Read Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5-4 Output Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
5-5 Image History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
