F-3
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
F-2 Read Cycle Setup
F
F-2 Read Cycle Setup
Setting up read cycle and triggering parameters will involve a series of decisions based on your
particular application, as follows:
1
Select the number of symbols to be read in a single cycle. The reader can read multiple symbols
in a single image frame.
2
Decide on the trigger type to be used: if serial, coose a serial character; if external, choose
either Level or Edge.
3
Designate how the read cycle should end (Timeout, New Trigger, Last Frame).
4
Select Capture Mode, Continuous Mode, or Rapid Mode.
5
Select Number of Captures (if in Rapid Capture Mode).
6
Set the Time Before First Capture and Time Between Captures, if any.
•Note: The capture rate increases as the frame size decreases.
