Appendices
M-6
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
M-4 Device Control
Sending <L1> activates the link between Output 1 (+) and Output 1 (–) of the host connector (regard-
less of Master Symbol or Output 1 status).
Sending <L2> activates the link between Output 2 (+) and Output 2 (–) of the host connector (regard-
less of Master Symbol or Output 2 status).
Sending <L3> activates the link between Output 3 (+) and Output 3 (–) of the host connector (regard-
less of Master Symbol or Output 3 status).
Sending <I> will turn the reader OFF, end the current read cycle, and will not allow the reader to enter
another read cycle until turned ON. This feature is useful during extended periods of time when no sym-
bols are being decoded, or the reader is being configured. Disabling the reader will not affect any com-
mands that have already been downloaded.
Sending <H> will turn the reader ON and allow it to enter read cycles.
M-4-1 Device Control by Serial Command
Output 1 Pulse
Output 2 Pulse
Output 3 Pulse
Disable Reader
Enable Reader
