H-19
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-11 Trend Analysis Output 1
H
H-11-1 Trend Analysis Mode
H-11 Trend Analysis Output 1
Output will be activated when the number of mismatches equals the value entered for Number to
Output On within the trigger window selected in Number of Triggers.
Output will be activated when the number of No-Reads equals the value entered for Number to
Output On within the trigger window selected in Number of Triggers.
Output will be activated when the number of decodes equals the value entered for Number to Output
On within the trigger window selected in Number of Triggers.
Usage: Useful in cases where the user doesn’t want to shut down for one condition
but wants to monitor quality and read conditions.
Definition: Applies
Trend Analysis
settings to
Output 1
.
With
Trend Analysis
, the user can track the occurrences and frequency of
mismatches, No-Reads, and the number of reads per trigger, and output the
results to any of three outputs.
Example: Trend Analysis Mode = No-Read
Trigger Evaluation Period= 25 triggers (read cycles)
Number to Output On = 4
In this example, the reader will activate an output when 4 No-Reads occur
within a period of 25 triggers (read cycles).
H-11-1 Trend Analysis Mode
Definition: Sets the trend condition
(Mismatch
,
No-Read
, or
Decodes per Trigger
) that
will activate the output.
Serial Cmd: <
K780,trend analysis mode
,trigger evaluation period,number to output on,
decodes per trigger threshold>
Default: No-Read
Options: 0 = Mismatch
1 = No-Read
2 = Decodes per Trigger
Mismatch
No-Read
Decodes per Trigger
H-11-2 Trigger Evaluation Period
Definition: The number of triggers to examine for the trend analysis condition.
Serial Cmd: <
K780,
trend analysis mode,
trigger evaluation period
,number to output on,
decodes per trigger threshold>
Default: 0
Options: 0 to 255
