Omron MicroHAWK V320-F User Manual

H-13
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-8 Setup Button
H
H-8-1 Global Status
H-8 Setup Button
The Setup button has four positions, selectable by the length of time the button is held down. Each
position can be programmed for any of eight options.
When set to Disabled, the Setup button does not function.
When selected, the Setup button is enabled and the function of each button position is selected by the
Setup Button Mode command.
When selected, the Setup button acts as a trigger for the imager to start and end read cycles. All other
button operations are inactive.
The parameter switch toggles between custom defaults and power-on settings. The condition is the
same as that achieved by sending the <Arc> and <Arp> commands consecutively.
Definition: Serves as a master switch to enable/disable the Setup button status.
Serial Cmd: <
K770,global status ,default on power-on,load Configuration Database,
save for power-on>
Default: Enabled
Options: 0 = Disabled
1 = Enabled
2 = Trigger
4 = Parameter Switch
H-8-1 Global Status
Disabled
Enabled
Trigger
In External
Level:
The read cycle endures for as long as the Setup button is pressed, unless a
timeout occurs and
Timeout is enabled for End of Read Cycle .
In External
Edge:
As with
Level , Edge allows a read cycle to be initiated by pressing the Setup
button, but unlike
Level , the read cycle ends with a good read output, a
timeout, or a new trigger.
Parameter Switch
H-8-2 Default on Power-On
Definition: When enabled, if the Setup button is held down on power-on the imager will
default to customer defaults and save for power-on. This is the same as
sending a
<Zrc> command.
Serial Cmd: <
K770, global status, default on power-on ,load Configuration Database,
save for power-on>
Default: Enabled
Options: 0 = Disabled 1 = Enabled
