Appendices
F-4
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
F-3 Multisymbol
•Note: If No-Read messages are disabled and there are No-Reads occurring, separators will only be inserted between
symbol data outputs.
Usage: Multisymbol is commonly used in shipping applications where a shipping
symbol contains individual symbols for part number, quantity, etc. This
feature allows on trigger to pick up all the symbols.
Definition: Multisymbol allows the user to define up to 100 symbols that can be read
in a single read cycle.
Conditions: The following conditions apply:
• Each symbol must be different to be read, unless in Rapid Capture
Mode, configured for “triggered capture”.
• The maximum number of characters in a read cycle is 3,000 for all
symbols.
• All No-Read messages are posted at the end of the data string, unless
output filtering is enabled.
• If more than one symbol is within the field of view at the same time,
symbol data may not be displayed in the order of appearance.
•
If
Matchcode Type
is set to
Sequential
or if
Trigger
is set to
Continuous
Read 1 Output, the reader will behave as if Number of Symbols were
set to 1, regardless of the user-defined configuration.
F-3-1 Number of Symbols
Definition: Number of Symbols is the number of different symbols that can be read in
a single read cycle.
Serial Cmd: <K222,number of symbols, multisymbol separator>
Default: 1
Options: 1 to 100
F-3-2 Multisymbol Separator
Usage: Used to delimit or separate data fields with a user defined character.
Definition:
Any valid ASCII character, inserted between each symbol read when Multisymbol
is set to any number greater than 1.
Serial Cmd: <K222,number of symbols,multisymbol separator>
Default: , (comma)
Options: Any available ASCII character.
