K-7
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
K-5 White Balance Settings
(QSXGA Color Only)
K
K-5-1 Red Gain
K-5 White Balance Settings (QSXGA
Color Only)
Sets the gain value for the red color channel of the image sensor and is a percentage value from 0%
(lowest gain) to 100% (highest gain). The color channel parameters are used to avoid unrealistic colors
so that objects that appear white to the human eye are rendered white in the final image. The default
value for this parameter is factory-calibrated.
Sets the gain value for the green color channel of the image sensor and is a percentage value from 0%
(lowest gain) to 100% (highest gain). The color channel parameters are used to avoid unrealistic colors
so that objects that appear white to the human eye are rendered white in the final image. The default
value for this parameter is factory-calibrated.
Sets the gain value for the blue color channel of the image sensor and is a percentage value from 0%
(lowest gain) to 100% (highest gain). The color channel parameters are used to avoid unrealistic colors
so that objects that appear white to the human eye are rendered white in the final image. The default
value for this parameter is factory-calibrated.
Definition: <K544,red gain,green gain,blue gain>
Default: Factory-Calibrated
Options: Any number between 0 – 100
K-5-1 Red Gain
K-5-2 Green Gain
K-5-3 Blue Gain
