Omron MicroHAWK V320-F User Manual

Appendices
H-28
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-14 ISO/IEC 15416 Symbol Quality
Output 1
Barcode Print Quality Guideline
Supported Symbologies:
Minimum Resolution: 4.0 Pixels Per Element
 Output on Overall Grade
 Overall Grade Threshold
• Code 128 / GS1-128
• UPC-A / UPC-E / EAN-13 / EAN-8
• Interleaved 2 of 5 / ITF-14
• Code 39
• Code 93
• Codabar
Usage: Lets the user know if symbol quality is less than acceptable.
Definition: If enabled, drives
Output if grade is under Overall Grade Threshold.
Serial Cmd: < K880, output on overall grade, overall grade threshold, edge
determination, edge determination threshold, decode, decode threshold,
contrast, contrast threshold, min reflectance, min reflectance threshold, min
edge contrast, min edge contrast threshold, modulation, modulation threshold,
defects, defects threshold, decodability, decodability threshold, quiet Zone,
quiet zone threshold >
Default: Disabled
Options: 0 = Disabled 1 = Enabled
Usage: Sets the threshold for driving the output.
Definition: Conforms to ISO/IEC 15416 symbol quality grading (A,B,C,D).
Serial Cmd: <
K880, output on overall grade, overall grade threshold, edge
determination, edge determination threshold, decode, decode threshold,
contrast, contrast threshold, min reflectance, min reflectance threshold, min
edge contrast, min edge contrast threshold, modulation, modulation threshold,
defects, defects threshold, decodability, decodability threshold, quiet Zone,
quiet zone threshold >
Default: Grade B
Options: 0 = Grade D
1 = Grade C
2 = Grade B
3 = Grade A
