Appendices
K-10
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
K-8 Illumination Brightness
When set to Constant, the illumination brightness is the same power level as the High setting.
However, the LEDs will always be on during a read cycle and will only be off between read cycles. This
cuts down on perceptible LED flashing.
When set to Extreme, illumination brightness enters Power Strobe mode. In this mode, illumination
is extremely intense, and can only be activated for a maximum of 1 ms.
For Configurable Output 3 (K812), Output On, Use as External Illumination Strobe to function,
Light Source must be set to External Strobe.
Definition: This feature allows you to adjust the brightness of the illumination LEDs.
Since the reader has control over the brightness of the illumination, it can
provide consistent brightness output between readers through a factory
calibration operation. Each of the brightness settings is calibrated to provide
the same level of intensity for each reader.
Serial Cmd: <K536,brightness,light source,fixed light on time,fixed light on delay
time>
Default: High
Options: 0 = Off
1 = Low
2 = Medium
3 = High
4 = Constant
5 = Extreme
Constant
Extreme
K-8-1 Light Source
Definition: The setting allows the user to change the illumination light source.
Serial Cmd:
<
K536,
brightness,
light source
,fixed light on time,fixed light on delay time>
Default: Outer LED Only
Options: 0 = External Strobe
1 = Inner White LED Only
2 = Inner Red LED Only
3 = Outer LED Only
External Strobe
