N-5
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
N-4 Format Extract
N
N-4-1 Output Index
N-4 Format Extract
N-4-1 Output Index
Definition:
Output Index
refers to the database entry you wish to modify with this command.
A formatted output is built by extracting data from a symbol’s original data
output and/or inserting user-defined characters.
It may be helpful to think of individual indexes as positions in the final formatted
output you wish to build. Starting with index # 1, enter either an extract or
insert command to begin building your desired output string. Then, with the
next index number, enter either an extract or insert command to continue
building the output string. Continue this process until you are finished building
the string.
Serial Cmd: <K740,output index,start location,length>
Options: 1 to 100
N-4-2 Start Location
Definition: Defines the location within the symbol data where the character extraction will
begin. The first character extracted will also be the first character in the
sequence displayed in user-defined output.
Serial Cmd: <K740,output index,start location,length>
Default: 0 (disabled)
Options: 0 to n (maximum number of characters in the symbol data).
N-4-3 Length
Definition: Defines the length (in consecutive characters) that will be extracted and
placed in user-defined output.
Serial Cmd: <K740,output index,start location,length>
Default: 0 (disabled; end of format cell array)
Options: 0 to n (maximum number of characters in the symbol data).
