H-25 Image Push to Host
Definition:
Image Storage Status determines whether or not Image Logging is active.
Note: Only images that have been processed by the decoder will be saved.
If Image Storage Status and RAM Drive Size in MB in <K764> are
switched from Disable to Enable, a cold boot of the reader will be required
in order to create the required RAM Drive, and it will take additional time for
the reader to re-initialize. Switching from Enable to Disable does not require
a cold boot.
Serial Cmd:
<K763,image storage status,stored image type,image storage,image file
format,
image quality,image scale
,file save options
>
Default: Disabled
Options: 0 = Disabled
1 = Enabled
H-25-1 Stored Image Type
Definition:
Stored Image Type
defines what kind of image you want to log in a read
cycle.
Serial Cmd:
<K763,image storage status,stored image type,image storage,image file
format,
image quality,image scale
,file save options
>
Default: No Read
Options: 1 = Good Read
2 = No Read
3 = Good Read + No Read
4 = Match
8 = Mismatch
12 = Match + Mismatch
15 = Good Read + No Read + Match + Mismatch
H-25-2 Image Storage
Definition:
Image Storage
defines which image will be stored within a read cycle.
• Good Read/Match/Mismatch: First qualified image or all qualified images.
• No Read: First image or all images that have an IP report.
Serial Cmd:
<K763,image storage status,stored image type,image storage,image file
format,
image quality,image scale
,file save options
>
Default: First Image in a Read Cycle
Options: 0 = First Image in a Read Cycle
1 = All Images in a Read Cycle
H-25-3 Image File Format
Definition:
Image File Format
defines the image format you want to use.
Serial Cmd:
<K763,image storage status,stored image type,image storage,image file
format,
image quality,image scale
,file save options
>
Default: PNG
Options: 0 = PNG
1 = JPG
To Next Page
