H-23
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-13 ISO/IEC 15415 Symbol Quality Output 1
H
H-11-4 Decodes per Trigger Threshold
H-13 ISO/IEC 15415 Symbol Quality
Output 1
Barcode Symbol Print Quality Test Specification – 2D Symbols
Supported symbologies:
Minimum Resolution: 6.0 Pixels Per Element
 Output on Overall Grade
 Overall Grade Threshold
• Data Matrix ECC200
• QR Code
• Micro QR Code
Usage: Lets the user know if symbol quality is less than acceptable.
Definition: If enabled, drives
Output if grade is under Overall Grade Threshold.
Serial Cmd: < K870, output on overall grade, overall grade threshold, symbol contrast,
symbol contrast threshold, modulation, modulation threshold, reflectance
margin, reflectance margin threshold, fixed pattern damage, fixed pattern
damage threshold, axial non-uniformity, axial non-uniformity threshold, grid
non-uniformity, grid non-uniformity threshold, unused ECC, unused ECC
threshold>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
Usage: Sets the threshold for driving the output.
Definition: Conforms to ISO/IEC 15415 symbol quality grading (A,B,C,D).
Serial Cmd: <
K870, output on overall grade, overall grade threshold, symbol contrast,
symbol contrast threshold, modulation, modulation threshold, reflectance
margin, reflectance margin threshold, fixed pattern damage, fixed pattern
damage threshold, axial non-uniformity, axial non-uniformity threshold, grid
non-uniformity, grid non-uniformity threshold, unused ECC, unused ECC
threshold>
Default: Grade B
Options: 0 = Grade D
1 = Grade C
2 = Grade B
3 = Grade A
