Omron MicroHAWK V320-F User Manual

Appendices
H-34
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-15 ISO/IEC 29158 Symbol Quality
Output 1
Automatic Identification and Data Capture – Direct Part Mark (DMP) Quality
Supported symbologies:
Minimum Resolution: 6.0 Pixels Per Element
 Output on Overall Grade
 Overall Grade Threshold
 Cell Contrast
• Data Matrix ECC200
Usage: Lets the user know if symbol quality is less than acceptable.
Definition: If enabled, drives Output if grade is under Overall Grade Threshold.
Serial Cmd: <
K890, output on overall grade, overall grade threshold, cell contrast, cell
contrast threshold, cell modulation, cell modulation threshold, fixed pattern
damage, fixed pattern damage threshold, axial non-uniformity, axial non-
uniformity threshold, grid non-uniformity, grid non-uniformity threshold,
unused ECC, unused ECC threshold>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
Usage: Sets the threshold for driving the output.
Definition: Conforms to ISO/IEC 29158 symbol quality grading (A,B,C,D).
Serial Cmd: <
K890, output on overall grade, overall grade threshold, cell contrast, cell
contrast threshold, cell modulation, cell modulation threshold, fixed pattern
damage, fixed pattern damage threshold, axial non-uniformity, axial non-
uniformity threshold, grid non-uniformity, grid non-uniformity threshold,
unused ECC, unused ECC threshold>
Default: Grade B
Options: 0 = Grade D
1 = Grade C
2 = Grade B
3 = Grade A
Usage: Lets the user know if symbol quality is less than acceptable.
Definition: If enabled, drives
Output if grade is under Symbol Contrast Threshold.
Serial Cmd: < K890, output on overall grade, overall grade threshold, cell contrast, cell
contrast threshold, cell modulation, cell modulation threshold, fixed pattern
damage, fixed pattern damage threshold, axial non-uniformity, axial non-
uniformity threshold, grid non-uniformity, grid non-uniformity threshold,
unused ECC, unused ECC threshold>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
