H-39
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-17 Other Outputs
H
H-17-1 Configurable Output 2
H-17 Other Outputs
H-17-1 Configurable Output 2
Serial Cmd: < K811, output on,output state,pulse width,output mode>
H-17-2 Trend Analysis Output 2
Serial Cmd: < K781, trend analysis mode,trigger evaluation period,number to output on>
H-17-3 ISO/IEC 16022 Symbol Quality Output 2
Serial Cmd: < K801, output on symbol contrast,symbol contrast threshold,output on print
growth,print growth threshold,output on axial non-uniformity,axial non- uniformity
threshold,output on UEC,UEC threshold>
H-17-4 ISO/IEC 15415 Symbol Quality Output 2
Serial Cmd: < K871 , output on overall grade, overall grade threshold, symbol contrast,
symbol contrast threshold, modulation, modulation threshold, reflectance
margin, reflectance margin threshold, fixed pattern damage, fixed pattern
damage threshold, axial non-uniformity, axial non-uniformity threshold, grid
non-uniformity, grid non-uniformity threshold, unused ECC, unused ECC
threshold>
