G-5
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
G-3 Aztec
G
G-2-8 ECC 130
G-3 Aztec
Usage: Used in document imaging, railway ticket validation, and some postal
applications.
Definition: A 2D matrix symbology built on a square grid with a square “bull’s-eye”
pattern at the center. Aztec can encode up to 3,832 numeric or 3,067
alphabetical characters, or 1,914 bytes of data.
The level of Reed-Solomon error correction used with Aztec is configurable, from
5% to 95% of the total data region. The recommended error correction level
is 23% of symbol capacity plus codewords.
Serial Cmd: <K458,status>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
