Appendices
I-8
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
I-5 Omron Microscan Symbol Quality
Output
I-5-1 Percent Cell Damage (Data Matrix Only)
Definition: When this feature is enabled, the cell damage percentage is appended to
data output.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-2 Total Read Time
Definition: The time that transpires between the image capture and the output of the
decoded data, including locate time.
When enabled, the total read time is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-3 Capture Time
Definition: Capture time (in milliseconds) is a fixed “overhead” that includes the time
of capture and transfer of the image.
When enabled, the capture time is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-4 Locate Time
Definition: The time in milliseconds from the start of image processing until the
symbol has been located and is ready to be decoded.
When enabled, the locate time is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-5 Decode Time
Definition: The time in milliseconds required to decode a symbol.
When enabled, the decode time is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
