I-9
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
I-5 Omron Microscan Symbol Quality Output
I
I-5-6 Pixel Per Element (Data Matrix Only)
I-5-6 Pixel Per Element (Data Matrix Only)
Definition: The number of pixels for each element, either dark or light for both x and
y directions.
When enabled, the pixels per element value is appended to the symbol
data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-7 Error Correction Level (Data Matrix Only)
Definition: Outputs the Data Matrix ECC level.
When enabled, the ECC level is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-8 Matrix Size (Data Matrix Only)
Definition: Defines the symbol matrix size, in number of pixels in both the x and y
axis.
When enabled, the matrix size value is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-9 Quiet Zone (Data Matrix Only)
Definition: When this feature is enabled, the size of the quiet zone is evaluated and
a PASS or FAIL message is appended to the symbol data.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-5-10 Symbol Angle (Data Matrix Only)
Definition: When this feature is enabled, the symbol orientation is appended to
data output as a degree value representing the angle of the Data Matrix
symbol’s L-shaped finder pattern relative to the reader.
Serial Cmd: <K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone,symbol angle>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
