Appendices
H-18
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
This is the default mode of operation in which the programmable output is activated when the Output
On condition has been met and held active for the duration of the selected pulse width.
The programmable output is activated when the Output On condition has been met and held active
until the opposite condition selected under Output On has been met.
For example, if No-Read is enabled under Output On, the programmable output will go active on a No-
Read and remain active until the opposite condition, a good read, occurs.
The programmable output is active when the Output On condition has been met and is held active until
a new read cycle begins.
•Note: All of the Output On modes are inhibited when any Output on Warning is active for Output 1.
Diagnostic Warning
Usage: Typically used when a discrete indication of a diagnostic condition is needed.
Definition: Activates discrete output when a diagnostic warning condition is met,
depending on the diagnostic option enabled.
In Read Cycle
Definition:
Activates a discrete output when the reader is in a read cycle.
H-10-1 Output State
Definition: Sets the active electrical state of the discrete output.
Serial Cmd: <
K810,
output on,
output state
,pulse width,output mode>
Default: Normally Open
Options: 0 = Normally Open 1 = Normally Closed
H-10-2 Pulse Width
Definition: Sets the time in 1 ms increments that the discrete output remains active.
Serial Cmd: <
K810,
output on,output state,
pulse width
,output mode>
Default: 500ms
Options: 0 to 65535(in 1 ms increments)
H-10-3 Output Mode
Definition: Sets the condition in which the discrete output is de-activated.
Serial Cmd: <
K810,
output on,output state,pulse width,
output mode
>
Default: Pulse
Options: 0 = Pulse
2 = Latch Mode 2
3 = Latch Mode 3
Pulse
Latch Mode 2 (Unlatch Opposite Condition)
Latch Mode 3 (Unlatch Re-enter Read Cycle)
