8-13
8 Advanced Settings
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
8-6 I/O
8
8-6-2 Symbol Grading
Enabled
The overall grade is formatted and attached to the decoded data as a value.
Edge Determination
Disabled
The edge determination is not formatted as part of the symbol output.
Enabled
The edge determination is formatted and attached to the decoded data as a value.
Decode
Disabled
The Decode is not formatted as part of the symbol output.
Enabled
The Decode is formatted and attached to the decoded data as a value.
Contrast
Disabled
The Contrast is not formatted as part of the symbol output.
Enabled
The Contrast is formatted and attached to the decoded data as a value.
Minimum Reflectance
Disabled
The minimum reflectance is not formatted as part of the symbol output.
Enabled
The minimum reflectance is formatted and attached to the decoded data as a value.
Minimum Edge Contrast
Disabled
The minimum edge contrast is not formatted as part of the symbol output.
Enabled
The minimum edge contrast is formatted and attached to the decoded data as a value.
Modulation
Disabled
The Modulation is not formatted as part of the symbol output.
Enabled
The Modulation is formatted and attached to the decoded data as a value.
Defects
Disabled
The Defects is not formatted as part of the symbol output.
