A-3
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
A
MicroHAWK V330-F
*1. These symbologies are supported based on Omron’s read capability validation standard. Omron recommends that validation be performed for each application.
*2. Unless otherwise specified, reading performance is defined with center of field of view, angle R=∞.
*3.
*4. In an electrically noisy environment, use only the V430-F in combination with a noise filter cable (V430-W
â–¡F-â–¡M) to ensure proper operation.
V330-F V330-Fâ–¡â–¡â–¡â–¡03M-â–¡â–¡â–¡ V330-Fâ–¡â–¡â–¡â–¡12M-â–¡â–¡â–¡ V330-Fâ–¡â–¡â–¡â–¡50C-â–¡â–¡â–¡
Symbologies *1
1D Symbologies
Code 39, Code 128, BC412, Interleaved 2 of 5, UPC/EAN, Codabar, Code 93, Pharmacode, PLANET,
Postnet, Japanese Post, Australian Post, Royal Mail, Intelligent Mail, KIX
2D Symbologies Data Matrix (ECC 0-200), QR Code, Micro QR Code, Aztec Code, DotCode
Stacked Symbologies PDF417, MicroPDF417, GS1 Databar (Composite and Stacked)
Reading
Performance
*2
Number of Reading Digits No Upper Limit (depending on bar width and reading distance)
Aiming Light Two Blue LEDs
Illumination
Inner LEDs: Four White and Four Red (Wavelength: 625 nm)
Outer LEDs:
None
Outer LEDs:
None
Outer LEDs:
None
Reading Distance /
Field of View
Refer to Read Ranges section for detail.
Pitch Angle (α) *3 ±30°
Skew Angle (β) *3 ±30°
Tilt Angle (γ) *3 ±180°
Image Capture
Focus Fixed Focus (Wide = 5.2 mm, Medium = 7.7 mm, Narrow = 16 mm)
Resolution 752 (H) x 480 (V) 1280 (H) x 960 (V) 2592 (H) x 1944 (V)
Color / Monochrome Monochrome CMOS Monochrome CMOS Color CMOS
Shutter Global Shutter Global Shutter Rolling Shutter
Frames per Second 60 fps 42 fps 5 fps
Exposure 50 to 100,000 μs
Image Logging FTP
Trigger Communication Trigger (Ethernet)
I/O Specifications
Input Signals Ethernet
Output Signals Ethernet
Communication
Connectivity Ethernet TCP/IP
Ethernet Specifications 100BASE-TX / 10BASE-T
Indicator LEDs PASS (Green), PWR (Green)
Power Supply Voltage Source: 44-57 VDC IEEE802.3af POE
Current Consumption Max Current: 0.10A
Environmental
Immunity
*4
Ambient Temperature
Range
Operating: 0 to 40° C Storage: -50 to 75° C (No Icing or Condensation)
Ambient Humidity Range Operating and Storage: 5% to 95% (Non-Condensing)
Ambient Atmosphere No Corrosive Gases
Vibration Resistance
(Destructive)
Oscillation Frequency: 10 to 150Hz, Half Amplitude: 0.35 mm, Vibration Direction: X/Y/Z, Sweep Time: 8
minute/count, Sweep Count: 10 times
Shock Resistance
(Destructive)
Impact Force: 150 m/s2, Test Direction: 6 directions, three times each (up/down, front/back, left/right)
Degree of Protection IEC 60529 IP40
Weight
Main Body Only 72 g
Packaging Weight Approx. 180 g (including packing)
Dimensions
Main Body Dimensions 40 (W) × 63 (D) × 24 (H) mm
Packaging Dimensions 170 (W) × 117 (D) × 86 (H) mm
Accessories ReadMeFirst, CE Compliance Sheet
LED Safety Standard IEC 62471-1: 2006 Risk-Exempt Group
Safety Standards
EN 55024:2010, EN 55032:2015 + AC:2016
FCC Part 15, Subpart B (Class B) UL60950-1
BIS
RCM, KC, EAC and BSMI Pending
Materials
Case Aluminum Diecast, Alumite (Black)
Reading Window Acrylic
Software WebLink
Pitch angle
Skew angle Tilt angle
