Appendices
F-14
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
Timeout or New Trigger
Usage: Useful in applications that require an alternative way to end the read
cycle. For example, if an assembly line should stop completely or the
intervals between objects are highly irregular.
Definition: Timeout or New Trigger is identical to Timeout except that a timeout or a
new trigger (whichever occurs first) ends the read cycle.
Last Frame
Usage: Useful in applications in which the number of captures needed can be
defined but the timeout duration varies.
Definition: Last Frame only applies to Rapid Capture Mode.
Last Frame or New Trigger
Usage: Useful in applications in which line speeds are irregular and a new
labelled object could appear before the last frame in a Rapid Capture
sequence.
Definition: Last Frame or New Trigger is identical to New Trigger except that a new
trigger or last frame (whichever occurs first) ends the read cycle.
Read Cycle Timeout
Definition: Read Cycle Timeout is the duration of the read cycle.
Serial Cmd: <K220,end of read cycle,read cycle timeout>
Default: 50 (x10 ms)
Options: 1 to 65535
