MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
H-1 I/O Parameters Serial Commands
Power On/Reset Counts <K406,power-on,resets,power-on saves,customer
default saves>
Time Since Reset (Read-Only) <K407,hours,minutes>
Service Message <K409,status,service message,threshold,resolution>
User-Defined Name <K412,user-defined name>
Serial Verification <K701,serial command echo status,control/hex output>
Quality Output <K704,quality output separator,decodes per trigger
status>
Symbol Data Output <K705,status,when to output,symbology identifier
status>
Read Duration Output <K706,status,separator>
No-Read Message <K714,status,message>
Output Object Info <K734,output frame number status,output coordinates
status>
LED Configuration <K737,ISO/IEC 16022 grade>
Output Indicators <K750,green flash LED status,target pattern LED
status,green flash duration>
Database Identifier Output <K759,status,separator character>
Image Push to Host <K764,Image Storage Status,Stored Image Type,Image
Storage, Image File Format,Image Quality,Image
Scale,File Save Options>
Image Push to Host Detail Setup <K763,Image Storage Location,FTP Host Info,Transfer
Optimization, RAM Drive Size in MB,Save Image
Until,Action at Image Storage Limit>
Setup Button <K770,global status,default on power-on,load
configuration database, save for power-on>
Setup Button Modes <K771,button option 1,button option 2,button option
3,button option 4>
Trend Analysis Output 1 <K780,trend analysis mode,number of triggers,number
to output on,decodes per trigger>
Trend Analysis Output 2 <K781,trend analysis mode,number of triggers,number
to output on,decodes per trigger>
Trend Analysis Output 3 <K782,trend analysis mode,number of triggers,number
to output on,decodes per trigger>
Diagnostic Output 1 <K790,service unit message status>
Diagnostic Output 2
<K791,service unit message status>
Diagnostic Output 3 <K792,service unit message status>
ISO/IEC 16022 Symbol Quality
Output 1
<K800,output on symbol contrast,symbol contrast
threshold,output on print growth,print growth
threshold,output on axial non-uniformity, axial non-
uniformity threshold,output on Unused ECC,Unused
ECC threshold>
ISO/IEC 16022 Symbol Quality
Output 2
<K801,output on symbol contrast,symbol contrast
threshold,output on print growth,print growth
threshold,output on axial non-uniformity, axial non-
uniformity threshold,output on Unused ECC,Unused
ECC threshold>
ISO/IEC 16022 Symbol Quality
Output 3
<K802,output on symbol contrast,symbol contrast
threshold,output on print growth,print growth
threshold,output on axial non-uniformity, axial non-
uniformity threshold,output on Unused ECC,Unused
ECC threshold>
Output 1 Parameters <K810,output on,output state,pulse width,output mode>
Output 2 Parameters <K811,output on,output state,pulse width,output mode>
Output 3 Parameters <K812,output on,output state,pulse width,output
mode>
