MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
I-6 ISO/IEC 15415 Symbol Quality Output
I
I-6-4 Modulation
I-6-4 Modulation
Definition: Modulation is calculated in accordance with the ISO 15415 specifica-
tion.
The Modulation grading is defined as follows.
A (4.0) if MOD
≥ 0.50
B (3.0) if MOD
≥ 0.40
C (2.0) if MOD
≥ 0.30
D (1.0) if MOD
≥ 0.20
F (0.0) if MOD
< 0.20
When enabled, the Modulation is attached to the symbol output data as
a value.
Serial Cmd: <K725, aperture, overall, contrast, modulation, reflectance margin, fixed
pattern damage, axial non-uniformity, grid non-uniformity, unused ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-6-5 Reflectance Margin
Definition: Reflectance Margin is calculated in accordance with the ISO 15415
specification.
When enabled, the Reflectance Margin is attached to the symbol output
data as a value.
Serial Cmd: <K725, aperture, overall, contrast, modulation, reflectance margin,
fixed pattern damage, axial non-uniformity, grid non-uniformity, unused
ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-6-6 Fixed Pattern Damage
Definition: Fixed Pattern Damage is calculated in accordance with the ISO 15415
specification.
When enabled, the Fixed Pattern Damage is attached to the symbol
output data as a value.
Serial Cmd: <K725, aperture, overall, contrast, modulation, reflectance margin, fixed
pattern damage, axial non-uniformity, grid non-uniformity, unused
ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-6-7 Axial Non-Uniformity
Definition: Axial Non-Uniformity is calculated in accordance with the ISO 15415
specification. The Axial Non-Uniformity grading is defined as follows.
A (4.0) if AN
≤ 0.06
B (3.0) if AN
≤ 0.08
C (2.0) if AN
≤ 0.10
D (1.0) if AN
≤ 0.12
F (0.0) if AN
> 0.12
When enabled, the Axial Non-Uniformity is attached to the symbol out-
put data as a value.
Serial Cmd: <K725, aperture, overall, contrast, modulation, reflectance margin, fixed
pattern damage, axial non-uniformity, grid non-uniformity, unused
ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
