Appendices
I-18
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
<VAL5>: Responds with a text report that summarized the grading of ISO/IEC29158.
This command will return the evaluation results, in a format similar to the one shown below.
I-8-5 Axial Non-Uniformity
Definition: Axial Non-Uniformity is calculated in accordance with the ISO 29158
specification.
When enabled, the Axial Non-Uniformity is attached to the symbol out-
put data as a value.
Serial Cmd: <K727, overall, cell contrast, cell modulation, fixed pattern damage, axial
non-uniformity, grid non-uniformity, unused ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-8-6 Grid Non-Uniformity
Definition: Grid Non-Uniformity is calculated in accordance with the ISO 29158
specification.
When enabled, the Grid Non-Uniformity is attached to the symbol out-
put data as a value.
Serial Cmd: <K727, overall, cell contrast, cell modulation, fixed pattern damage, axial
non-uniformity, grid non-uniformity, unused ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-8-7 Unused ECC
Definition: Unused ECC is calculated in accordance with the ISO 29158 specifica-
tion.
When enabled, the Unused ECC is attached to the symbol output data
as a value.
Serial Cmd: <K727, overall, cell contrast, cell modulation, fixed pattern damage, axial
non-uniformity, grid non-uniformity, unused ECC>
Default: Disabled
Options: 0 = Disabled 1 = Enabled
I-8-8 Grading Report
