J-7
Appendices
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
J-3 Matchcode Type
J
J-3-6 Sequence on Mismatch
As an example of Sequence on Mismatch Enabled, consider the following decodes:
As an example of Sequence on Mismatch Disabled, consider the following decodes:
Master Symbol Decoded Symbol Master Symbol after Decode
001 001 002
002 002 003
003 abc 004 (sequenced on mismatch)
004 004 005
005 def 006 (sequenced on mismatch)
006 ghi 007 (sequenced on mismatch)
007 007 008
Master Symbol Decoded Symbol Master Symbol after Decode
001 001 002
002 002 003
003 abc 004 (sequenced because of previous match)
004 004 005
005 def 006 (sequenced because of previous match)
006 ghi 006 (not sequenced)
006 006 007
