Omron MicroHAWK V320-F User Manual

Appendices
K-14
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
Open removes minor light defects of dark cells by performing a Dilate function followed by an Erode
function.
Close removed minor dark defects of light cells by performing an Erode function followed by a Dilate
function.
Open (Connect Dark)
Close (Separate Dark)
K-10-2 Operator Size
Definition: Operator Size determines the size of the area or “pixel neighborhood”
(measured in pixels) in which the morphological operation is being performed.
Serial Cmd: <K551,0,morphological operation,operator size>
Default: Small
Options: 3 = Small (3 pixels by 3 pixels)
5 = Medium (5 pixels by 5 pixels)
7 = Large (7 pixels by 7 pixels)
