Appendices
M-8
MicroHAWK V320-F / V330-F / V420-F / V430-F Barcode Reader User Manual
M-5-5 Read Next Symbol as Master Symbol
Definition:
After you’ve set the size in the database, you can order the reader to read
the next symbol as the master symbol for any given master symbol number.
Serial Cmd: <Gmaster symbol number>
To store the next symbol decoded as master symbol # 1, send:
<G>
or
<G1>
.
To store the next symbol decoded as the master symbol for any other
master
symbol database number, send:
<Gmaster symbol number [1-10]>
.
For example,
<G5>
will cause the next symbol read to be entered as master
symbol # 5.
M-5-6 Request New Master Status
Usage: Informs the user when a new master symbol is pending and which position
it is in.
Definition: Returns the position in the master symbol database that will be loaded on
the next read.
Serial Cmd: <NEWM>
The reader returns:
<NEWM/next master to load>
Once a symbol has been read and loaded, the status will be cleared and the
response will be
<NEWM/0>
.
(See also New Master Pin in Matchcode.)
M-5-7 Delete Master Symbol Data
Definition:
You can directly delete the master symbol data by serial command.
Serial Cmd: <K231,master symbol number,>
To delete a master symbol, enter the database number and a comma, but
leave the data field empty. For example, to delete master symbol # 5, send
the following: <K231,5,>. The command is entered with a blank master
symbol data field, which tells the reader to delete the selected master
symbol
from the database.
