Panasonic KX-UT123

RTCP_SEND_BY_SDP_n
Parameter Name Example RTCP_SEND_BY_SDP_1, RTCP_SEND_BY_SDP_2, …,
RTCP_SEND_BY_SDP
_6
Value Format Integer
Description Specifies whether to send RTCP signals by SDP (Session Description
Protocol).
Value Range 0–1
– 0: Send RTCP signals using the value specified in
"RTCP_INTVL_
n
", if the "RTCP_ENABLE_n" parameter is enabled.
– 1: Send RTCP signals using the value specified in the SDP attribute
"a=rtcp:".
Default Value 0
RTP_CLOSE_ENABLE_n
Parameter Name Example RTP_CLOSE_ENABLE_1, RTP_CLOSE_ENABLE_2, …,
RTP_CLOSE_ENABLE
_6
Value Format Boolean
Description Specifies whether to enable processing to close held RTP sockets.
Value Range
• Y (Enable RTP Close)
• N (Disable RTP Close)
Default Value
Y
5.6.3 Miscellaneous VoIP Settings
OUTBANDDTMF_n
Parameter Name Example OUTBANDDTMF_1, OUTBANDDTMF
_2
, …, OUTBANDDTMF_6
Value Format Boolean
Description Specifies the method for transmitting DTMF tones.
Value Range
• Y (Outband [use telephone
-event])
• N
(Inband)
Note
• If set to "Y", DTMF tones will be sent through SDP, compliant
with RFC 2833.
• If set to "N", DTMF tones will be encoded in the RTP stream.
Default Value
Y
Web User Interface Reference DTMF Type (Page 119)
Document Version 2013-03 Administrator Guide 239
