Panasonic KX-UT123

3.1 Phone User Interface Programming
This section provides information about the features that can be configured directly from the unit, but that are
not mentioned in the Operating Instructions.
To enter direct commands, use the dial keys and soft buttons on the unit.
For details about the other available features, settings and key operations on the phone user interface, refer
to the Operating Instructions on the Panasonic Web site (® see Introduction).
3.1.1 Phone User Interface Feature List and Direct Commands
The following table shows additional features programmable with direct commands. These commands are
hidden from end users.
Direct
Command
Feature Ref.
[#][1][3][6] Resetting the unit
*1
Page 29
[#][2][8][9] Delete all items of phonebook
*1
Page 56
[#][5][3][4] Embedded web Page 22
[#][7][3][1] Terminal No. Page 56
[#][7][3][9] Reset Web ID/Password
*1
Page 57
[#][2][7][6] Sound Quality
*2
Page 57
*1
Not displayed on the LCD of the unit.
*2
KX-UT113/KX-UT123/KX-UT133/KX-UT136 only
3.1.2 Phonebook deletion
You can delete all items in the phonebook by performing the procedure below from the unit.
To delete all items in the phonebook
1. Press
Setting
or
Setup
.
2. Press [#][2][8][9].
3. Press [
] or [ ] to select "Yes" to delete all items in the phonebook, and then press [ENTER].
3.1.3 Terminal Number Settings
You can select the terminal number of the unit that you are using from "Terminal 1"–"
Terminal 9", and
"Auto". The default setting is "Auto". "Auto" does not assign a fixed terminal number to the unit.
If multiple units try to access the same router simultaneously, errors can occur. Assigning a terminal number
1 to 9 to each of the units may prevent such errors.
To assign a terminal number to the unit
1. Press
Setting
or
Setup
.
2. Press [#][7][3][1].
3. Press [ ]
or [
]
to select the desired terminal number ("Auto", "Terminal 1"
–"Terminal 9"), and then
press [ENTER].
56 Administrator Guide Document Version 2013-03
3.1.3 Terminal Number Settings
