Panasonic KX-UT123

Result Message Description Applicable Screens
Failed (Invalid File) The operation failed because:
• The imported UTF-16 text file has an
invalid BOM (Byte-order Mark).
4.6.6 Import Phonebook
• The firmware file is corrupted or invalid.
4.7.2 Local Firmware
Update
Failed (File Size Error)
The operation failed because:
• The size of the imported phonebook is
too large.
4.6.6 Import Phonebook
• The size of the firmware file is
insufficient.
4.7.2 Local Firmware
Update
Failed (Busy) The operation failed because:
• When attempting to import/export the
phonebook data, the connection with
the unit has been disconnected.
4.6.6 Import Phonebook
4.6.7 Export Phonebook
Memory Full The operation failed because:
• When attempting to import the
phonebook data, the total number of
phonebook entries, including the
existing
entries,
exceeds the limit (of up
to 100 [for the KX-UT113]/500 [for the
KX-UT123/KX-UT133/KX-UT136/
KX-UT248] entries).
4.6.6 Import Phonebook
No Data The operation failed because:
• The imported phonebook file contains
no valid phonebook entries.
4.6.6 Import Phonebook
• No phonebook entry is registered in the
export source the unit.
4.6.7 Export Phonebook
*1
"Failed (Transfer Failure)
" may not be displayed depending on your Web browser.
Notice
• Do not
click the navigation buttons of your Web browser or open a new window to display the screen.
Otherwise, an error ("403 Forbidden") will occur when you click [Save].
1.1.7 Other Network Settings
1.1.7.1 Firewall and Router Setup
When the unit is connected to a network that is protected by a firewall and/or router, you need to configure the
firewall and/or router so that they do not block communication from the IP address and port number used by
the unit.
