Panasonic KX-UT123

DTMF_RELAY_n
Parameter Name Example DTMF_RELAY_1, DTMF_RELAY_2, …, DTMF_RELAY_6
Value Format Boolean
Description Selects whether DTMF tones are sent in the SIP INFO message.
Value Range
• Y
• N
Note
• If
set
to "Y", DTMF tones will be sent in the SIP INFO message.
• If set to "N", the method selected in "OUTBANDDTMF_n" will be
used.
Default Value
N
Web User Interface Reference DTMF Relay (Page 119)
OUTBANDDTMF_VOL
Value Format Integer
Description Specifies the volume (in decibels [dB]) of the DTMF tone using RFC
2833.
Value Range -63–0
Default Value -5
INBANDDTMF_VOL
Value Format Integer
Description Specifies the volume (in decibels [dB]) of in-band DTMF tones.
Value Range -46–0
Default Value -5
TELEVENT_PAYLOAD
Value Format Integer
Description Specifies the RFC 2833 payload type for DTMF tones.
Note
• This setting is available only when "OUTBANDDTMF_n" is set to
"Y".
Value Range 96–127
Default Value 101
240 Administrator Guide Document Version 2013-03
5.6.3 Miscellaneous VoIP Settings
