packets might be blocked by the router, depending on the SIP server. To avoid this problem, this setting is
required. For details, see 1.1.7.2 NAT (Network Address Translation) Setup.
4.3.6.1 Global IP Address
Global IP Address
Description Specifies the global IP address of your network.
Note
• You must enter a value in this field if at least 1 of [Line 1]–
[Line x] is set to [Yes], or when port numbers are specified in
[Channel 1–25].
• The available line number and the channel number vary
depending on the type of the unit being used.
• The global IP address will reflect SIP messages and RTP
packets.
Value Range IP address in dotted-decimal notation ("n.n.n.n" [n=0–255]) (Max.
15 digits)
Default Value Not stored.
92 Administrator Guide Document Version 2013-03
4.3.6 Static NAPT Settings
