Panasonic MN101L Series

Chapter 7
I/O Port
Control Registers VII - 11
 Port 8 Input Register (P8IN: 0x03F28)
bp 76543210
Bit name - - P8IN5-0
At reset00XXXXXX
AccessRRRRRRRR
bp Bit name Description
7-6 - Always read as 0.
5-0 P8IN7-0
Input data
0: Input "Low" (V
SS
-level)
1: Input "High" (V
DD30
-level)
