Panasonic MN101L Series

Chapter 13
Serial Interface
Control Registers XIII - 25
 BRTM01 Count Clock Select Register (BRTM_S01_CK)
bp76543210
Bit name
BRTM_S1
_CK3
BRTM_S1
_CK2
BRTM_S1
_CK1
BRTM_S1
_CK0
BRTM_S0
_CK3
BRTM_S0
_CK2
BRTM_S0
_CK1
BRTM_S0
_CK0
Initial value 0 0 0 0 0 0 0 0
Access R/W R/W R/W R/W R/W R/W R/W R/W
bp Bit name Description
7-4
BRTM_
S1_CK3-0
BRTM1 count clock selection
0000: BRT1SCLK
0001: BRT1SCLK/2
0010: BRT1SCLK/4
0011: BRT1SCLK/8
0100: BRT1SCLK/16
0101: BRT1SCLK/32
0110: BRT1SCLK/64
0111: BRT1SCLK/128
1000: BRT1SCLK/256
1001: SYSCLK
1010: SYSCLK/2
1011: SYSCLK/4
1100: SYSCLK/8
1101: SYSCLK/16
1110: SYSCLK/32
1111: SYSCLK/64
*BRT1SCLK is the clock selected with BRTM_S_CKSEL.BRTM_S1_CKSEL
3-0
BRTM_
S0_CK3-0
BRTM0 count clock selection
0000: BRT0SCLK
0001: BRT0SCLK/2
0010: BRT0SCLK/4
0011: BRT0SCLK/8
0100: BRT0SCLK/16
0101: BRT0SCLK/32
0110: BRT0SCLK/64
0111: BRT0SCLK/128
1000: BRT0SCLK/256
1001: SYSCLK
1010: SYSCLK/2
1011: SYSCLK/4
1100: SYSCLK/8
1101: SYSCLK/16
1110: SYSCLK/32
1111: SYSCLK/64
*BRT0SCLK is the clock selected with BRTM_S_CKSEL.BRTM_S0_CKSEL
