Chapter 17
LCD
XVII - 6 Control Registers
LCD Mode Control Register 1 (LCDMD1: 0x03E81)
bp 76543210
Bit name LCVREN - - LCVRO4-0
At reset00000000
Access R/W R R R/W R/W R/W R/W R/W
bp Bit name Description
7 LCVREN
REFVOL enable control
0: stop
1: start
6-5 - Always read as 0.
4-0 LCVRO4-0
Output voltage of REFVOL (Incremented by 0.05 V)
00000: 0.9 V
00001: 0.95 V
|
10010: 1.8 V
10011-11111: Setting prohibited
