Panasonic MN101L Series

Chapter 17
LCD
Control Registers XVII - 11
 LCD Port Control Register 2 (LCCTR2: 0x03E88)
bp 76543210
Bit name SEGSL19 SEGSL18 SEGSL17 SEGSL16 SEGSL15 SEGSL14 SEGSL13 SEGSL12
At reset00000000
Access R/W R/W R/W R/W R/W R/W R/W R/W
bp Bit name
Description
MN101LR05D MN101LR04D MN101LR03D
7 SEGSL19
SEG19/P50 selection
0: P50
1: SEG19
SEG19/P40 selection
0: P40
1: SEG19
SEG11/P40 selection
0: P40
1: SEG11
6 SEGSL18
SEG18/P51 selection
0: P51
1: SEG18
SEG18/P41 selection
0: P41
1: SEG18
SEG10/P41 selection
0: P41
1: SEG10
5 SEGSL17
SEG17/P52 selection
0: P52
1: SEG17
SEG17/P42 selection
0: P42
1: SEG17
SEG9/P42 selection
0: P42
1: SEG9
4 SEGSL16
SEG16/P53 selection
0: P53
1: SEG16
SEG16/P43 selection
0: P43
1: SEG16
SEG8/P43 selection
0: P43
1: SEG8
3 SEGSL15
SEG15/P54 selection
0: P54
1: SEG15
SEG15/P44 selection
0: P44
1: SEG15
SEG7/P44 selection
0: P44
1: SEG7
2 SEGSL14
SEG14/P55 selection
0: P55
1: SEG14
SEG14/P45 selection
0: P45
1: SEG14
Must be set to "0".1 SEGSL13
SEG13/P56 selection
0: P56
1: SEG13
SEG13/P62 selection
0: P62
1: SEG13
0 SEGSL12
SEG12/P57 selection
0: P57
1: SEG12
SEG12/P46 selection
0: P46
1: SEG12
