Setting up Compax3 C3I22T11
128 192-120114 N5 C3I22T11 June 2008
The machine reference offset is used to determine the actual reference point for
positioning.
That is: Zero point = Machine zero + Machine zero offset
Note: If the machine zero proximity switch is at the positive end of the travel range,
the machine zero offset must be = 0 or negative.
A change in the machine reference offset does not take effect until the next
machine reference run.
Machine zero speed and acceleration
With these values you can define the motion profile of the machine zero run.

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
