Communication
C3I22T11
316 192-120114 N5 C3I22T11 June 2008
Definition of the states of the programmable status bits (PSBs):
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Enable2
PSB2
Enable1
PSB1
Enable0
PSB0
Reserved
="1": Set PSB
="0": leave PSB unchanged
Reserved
PSB2 PSB1
PSB0
The Bits 0 ... 2 monitor the states of the status bits at the end of a motion set, if the
bits were enabled via the respective Enable.
If Enable is set to ”0”, the respective PSB remains unchanged at the end of the
motion set.
PSB0: Status word 2 Bit 12
PSB1: Status word 2 Bit 13
PSB2: Status word 2 Bit 14
