Parker Compax3 Series User Manual

Specifications
C3I22T11
402 192-120114 N5 C3I22T11 June 2008
Braking operation Compax3SxxxV4 3AC
Controller type S015V4 S038V4 S075V4 S150V4 S300V4
Capacitance / storable
energy
235μF /
37Ws
235μF /
37Ws
470μF /
75Ws
690μF /
110Ws
1100μF /
176Ws
Minimum braking- resistan-
ce
100Ω 100Ω 56Ω 33Ω 15Ω
Recommended nominal
power rating
60 ...
100W
60 ...
250W
60 ... 500
W
60 ... 1000
W
60 ... 1000
W
Maximum continuous cur-
rent
10A 10A 15A 20A 30A
Braking operation Compax3MxxxD6 (axis controller)
Device type
Compax3
M050 M100 M150 M300
Capacitance /
storable energy
110µF/
18Ws at 400V
10Ws at 480V
220µF/
37Ws at 400V
21Ws at 480V
220µF/
37Ws at 400V
21Ws at 480V
440µF/
74Ws at 400V
42Ws at 480V
Braking operation of Compax3HxxxV4
Controller type H050V4 H090V4 H125V4 H155V4
Capacitance / storable
energy
2600μF /
602Ws
3150μF /
729Ws
5000μF /
1158Ws
5000μF /
1158Ws
Minimum braking- resistan-
ce
24Ω 15Ω 8Ω 8Ω
Maximum continuous cur-
rent
30A 45A 83A 83A
Ballast resistors for Compax3
Braking Resistor (see page 363) Device Rated Power
BRM08/01 (100Ω)
Compax3S025V2
Compax3S015V4
Compax3S038V4
60W
BRM05/01 (56Ω)
Compax3S063V2
Compax3S075V4
180W
BRM05/02 (56Ω)
Compax3S075V4 570W
BRM10/01 (47Ω)
Compax3S150V4 570W
BRM04/01 (15Ω)
Compax3S150V2
Compax3S300V4
Compax3MP20D6
570W
BRM04/02 (15Ω)
Compax3S150V2
Compax3S300V4
Compax3MP20D6
740W
BRM04/03 (15Ω)
Compax3S300V4
Compax3MP20D6
1500W
BRM09/01 (22Ω)
Compax3S100V2 570W
BRM11/01 (27Ω)
Compax3H0xxV4 3500W
BRM13/01 (30Ω)
Compax3MP10D6
Compax3MP20D6**
500 W
BRM14/01 (15Ω)
Compax3MP10D6*
Compax3MP20D6
500 W
BRM12/01 (18Ω)
Compax3H1xxV4 4500W
*for Compax3MP10D6 2x15Ω in series
**for Compax3MP20D6 2x30Ω parallel
