Appendix F: PMS Multi-Drop Protocol (MiniLaz Emulation)
Page F-6 Lasair II Particle Counter Operations Manual
Multi-Drop CTD2 Command Data Format
The data format for the CTD2 command is essentially the CSV format with several
<CR><LF> characters inserted. All analog data channels are printed regardless of
how many are enabled. Unused analog channels will print “Nan”. See Appendix E,
"Comma Separated Value (CSV) Format".
C5 ########
Channel 5 Raw Differential Counts
TM ###.##
Temperature (Degrees F)
RH ###.##
Relative Humidity (percent)
RTD2
Date, Time, Sensor_Name, Sensor_Type, Sensor_S/N,
Statistics, Loc_chg, Location, Manifold_Index,
Laser_OK, Flow_OK, Sample_Valid, Sample_time, Volume_Units, Volume,
Num_Particle_Channels, Size_1, Counts_1, S2, C2, S3, C3, S4, C4, S5, C5, S6, C6,
Num_Analog_Chan,
A_Name1, A_Units1, A_Avg1, A_Min1, A_Max1,
A_Name2, A_Units2, A_Avg2, A_Min2, A_Max2,
A_Name3, A_Units3, A_Avg3, A_Min3, A_Max3,
A_Name4, A_Units4, A_Avg4, A_Min4, A_Max4,
A_Name5, A_Units5, A_Avg5, A_Min5, A_Max5,
A_Name6, A_Units6, A_Avg6, A_Min6, A_Max6
