Using Edit Mode - - General Procedure

Lasair II Particle Counter Operations Manual Page 5-3

Using Edit Mode - - General Procedure

Setting parameter values in Lasair II particle counter Setup Screens

1 Verify that the screen has a blue pencil icon in the upper left

corner. If the icon is present, the screen is a setup screen and

values can be changed.

2 Press the Enter key to enable the Edit Mode.

3 Press the Tab Keys to move the cursor to the parameter to be

changed.

4 Press the Enter key to access the parameter.

5 Press the arrow or Enter keys to change the parameter.

6 Press Tab or Enter to record the desired setting.

7 Use the Return Arrow softkey to Exit the Edit Mode.
