Appendix N: International Precautions

Page N-2 Lasair II Particle Counter Operations Manual

Hazard Symbols

The meaning of hazard symbols appearing on the equipment is as follows:

Symboles de risque

Des symboles représentant les risques sont placés sur l'appareil. Leur signification

est la suivante:

Symbol Nature of Hazard

Attention, consult

accompanying documents.

Dangerous High Voltage

Symbole Nature du risque

Attention, consulter les

documents d’accompagnement

Danger Electricite
