4-20 mA Output
Lasair II Particle Counter Operations Manual Page J-5
6 Press the Enter softkey again to activate the Field Edit Mode. The numbers in
the field will turn blue and a blinking cursor will appear.
7 Use the Up, Down, Right, Left, Delete , and Insert softkeys to enter
the value you want in the field.
8 When the value is correct, press the Enter button again to save the value and
disable the Field Edit Mode.
NOTE:
The Scale value must be greater than zero.
9
Use the Up and Down softkeys again to navigate to the next Scale Field you
want to edit.
10 Repeat steps 6–9 until all Scale fields have been correctly set.
11 Press the Enter button again to save the value and disable the Field Edit Mode.
12 Navigate to the Update button box by pressing the Forward Tab softkey.
13 Use the Right or Left softkeys to highlight Continuous or End of Sample output.
14 Press the Enter softkey to enable the option you want.
15 Repeat steps 12–14 to set each of the remaining buttons to the needed
configuration.
16 When all settings are correct, press the Return Arrow softkey to disable
Edit Mode.
