Penlon Prima 460 - Page 115

Prma 460 107 User Manual
Appendix 5
as Flow Schematc
NOTE
The schematc represents the gas path wth the absorber ‘ON’
(e the absorbent canster n the ‘locked-on’ poston
1 Ventlator bellows
2 Bag/ventlator swtch
3 Absorbent canster
4 Fresh gas flow from anaesthetc machne
5 Inspratory non-return valve
6 Adustable pressure lmtng valve (APL) valve
7 Breathng bag
8 Patent
9 Expratory non-return valve
10 Manometer
11 Pressure montor sample lne
12 Ventlator drve gas
13 Oxygen montor sensor (fuel cell type)
14 Sprometer flow sensors
Inspratory as Path
A Patent as from bellows
B Through the bag/ventlator swtch
 Down to absorbent canster
D Through the absorbent
E Fresh gas flow from anaesthetc machne
F Into the nspratory non-return valve
 Through nspratory connector to patent breathng crcut
E
G
D
F
C
B
A
1
12
7
6
10
14
14
9
2
4
11
5
13
3
8
