Description
3.13.9 Alarms
User adustable alarms
Use the menu systems to set the requred lmts Press the menu swtch (1) on the front panel,
and select ALARM SETTIN, or use the touchscreen
Hgh Prorty Alarms Hgh prorty alarms are accompaned by fve ascendng tones that are repeated
Medum Prorty Alarms Medum prorty alarms are accompaned by three ascendng tones that are repeated
Low Prorty Alarms Low prorty alarms are accompaned by one tone, not repeated
Alarm Prorty Trgger Mute
tme
Set by
Ventlator noperatve (vent nop) Hgh Internal system falure heck error log for key None Automatc
Outlet blocked Hgh Postve pressure on PEEP sensor exceeds 122 cmHO, due to blocked exhaust
valve outlet
None Automatc
Low supply pressure Hgh Suppled drve gas pressure on pressure swtch s less than 235 kPa (35 ±1 ps) None Automatc
Low arway pressure Hgh Bellows drve gas pressure sensor fals to see at least 75% of set target level
(pressure control)
120 s Automatc
Hgh drve gas pressure Hgh Arway and drve gas pressure exceeds calculated target level 120 s Automatc
Hgh contnuous pressure Hgh PEEP +10 cmHO for 1 cycle, or PEEP +5 cmHO for 3 cycles A PEEP value of 4
cmHO s used for PEEP values ≤4 Standby the alarm trggers after 15 seconds
120 s Automatc
Hgh arway pressure Hgh Arway pressure sensor Pressure reaches set lmt (10 to 80 cmHO adustable) 30 s User/Default
Negatve arway pressure Hgh Arway pressure sensor Breathng system pressure exceeds (-)10 cmHO 120 s Automatc
heck pressure sensng Hgh Arway pressure sensor Breathng system pressure exceeds (-)10 cmHO 120 s Automatc
Low tdal volume (VT) Hgh a) Expratory sprometer sensor Measured VT less than 50% of volume set
b) Expratory sprometer sensor dsconnected
120 s User/Default
Low mnute volume (VM) Hgh Expratory sprometer sensor alculated volume lower than -50% of volume set 120 s User/Default
Apnoea Hgh Breath not detected wthn 15 s Mute tme varable n spontaneous mode only 15-180 s Automatc
Hgh tdal volume (VT) Hgh Inspratory sprometer sensor - measured value exceeds 150% of set value 120 s User/Default
Hgh mnute volume (VM) Hgh Inspratory sprometer sensor - calculated value exceeds 150% of set value 120 s User/Default
Hgh Oxygen concentraton % Hgh Oxygen montor (fuel cell type)  Measured O % exceeds set value 120 s User/Default
Low Oxygen concentraton % Hgh Oxygen montor (fuel cell type) Measured O % lower than set value 120 s User/Default
Oxygen sensor fault Hgh Oxygen montor (fuel cell type)  Sensor dsconnected 120 s Automatc
Power about to fal Hgh Machne s runnng on battery power and s about to shut down because battery
power s depleted to a crtcal level
(a) Less than 5 mnutes battery lfe remans
(b) When total power falure s mmnent, the shutdown procedure starts
automatcally
None Automatc
Alarm prorty fault Hgh An error prorty has been generated, that s dfferent from the audble alarm tone
that s beng played
None None
Alarm speaker fault Hgh Malfuncton of the alarm speaker None None
UI watchdog fault Hgh UI not actve, no sgnal receved from UI to the core Ventlaton wll reman actve 30 s None
Flowmeter sensor fault Medum Indvdual gas sensor falure The gas flow dsplay s dsabled (see 3112) 120 s None
Rate or Rato error Medum The parameters set for ventlaton cannot be acheved 120 s None
Battery power fal Medum Battery s not relable or Battery fault 120 s None
Sensor cable fault Low Absorber cable fault None None
Low battery Low Less than 20 mnutes battery power avalable None None
A power falure Low Mans power not avalable, runnng on battery None None
Oxygen sensor low output
Low
Oxygen oncentraton s less than the low alarm lmt None None
PRVC high pressure Low Above PRVC pressure range (see 3.13.4) None None
PRVC low pressure Low Below PRVC pressure range (see 3.13.4) None None
Note
1 In prmary alarm falure condtons, the secondary alarm wll sound, but wll be subect to volume control
2 The Alarm mute symbol s dsplayed adacent to the Icons
The symbol s shown wth a numerc value (1) that represents seconds of mute tme that remans
3 If a Masmo Nomolne AX+ or OR+ module s nstalled refer to Appendx 7 - Alarms
